What is a Wedge Wire Strainer

JX Filtration October 22, 2025 Wedge Wire Strainer

A stainless steel Wedge Wire Strainer , also known as a wedge wire filter, wedge wire screen pipe, or Johnson screen, is a precision filtration and screening product made by welding stainless steel wires.

Its core feature lies in its unique V-shaped (wedge-shaped) wire structure. During manufacturing, stainless steel wires with a V-shaped cross-section are welded onto circular or square support rods using a special welding technique, forming uniform and precise slots.

This design provides a smooth surface and trapezoidal slot openings—narrower at the filtration surface and wider toward the inside of the screen. Such a structure effectively prevents particles from becoming trapped in the slots, thereby enhancing filtration efficiency and throughput while minimizing clogging.

Thanks to its excellent corrosion resistance, high mechanical strength, and long service life, the stainless steel wedge wire screen is widely used in industries such as water treatment, petrochemical, mining, and food & beverage processing, where efficient solid-liquid separation is essential.
